| Parameter | Model Sene 3.5kW | Model Sene 7kW |
|---|---|---|
| Input | ||
| Input Voltage | 230VAC ± 10% | 230VAC ± 10% |
| Rated Frequency | 50/60Hz | 50/60Hz |
| Output | ||
| Maximum Current | 16A | 32A |
| Maximum Power | 3.5kW | 7kW |
| Current Level Adjustment | Multiple levels can be adjusted | Multiple levels can be adjusted |
| System | ||
| Charging Connector | Type 2, GB/T | Type 2, GB/T |
| Cable Length | 5m | 5m |
| Housing Material | PC + ABS | PC + ABS |
| Screen & Indicator | 128*64 dots LCD | 128*64 dots LCD |
| RFID Reader | ISO 14443A / ISO 14443B | ISO 14443A / ISO 14443B |
| Authorization Mode | Plug & Charge | Plug & Charge, RFID |
| Protection | ||
| Ingress Protection | IP55 (Connector head IP67) | IP55 (Connector head IP67) |
| Protection Features | Over Current, Residual Current, Ground Protection, Surge Protection, Over/Under Voltage, Over Temperature, Relay Welding Detection | Over Current, Residual Current, Ground Protection, Surge Protection, Over/Under Voltage, Over Temperature, Relay Welding Detection |
| Leakage Protection | A + DC 6mA | A + DC 6mA |
| Withstand Voltage | 1500VAC | 1500VAC |
| Certification Standard | IEC-62196-1, IEC-62196-2, IEC-61851-1, IEC-62752 | IEC-62196-1, IEC-62196-2, IEC-61851-1, IEC-62752 |
| Warranty | 2 years | 2 years |
| Environment | ||
| Relative Humidity | 5% - 85% RH | 5% - 85% RH |
| Working Temperature | -30℃ to 45℃ | -30℃ to 45℃ |
| Cooling | Natural convection | Natural convection |
| Operating Altitude | <2000m | <2000m |
| Package | ||
| Dimension (W×H×D) | 106mm * 246mm * 70mm | 106mm * 246mm * 70mm |
| Net Weight | 2.4~2.8 kg | 2.4~2.8 kg |
·After-Sales Service: Free installation guidance and troubleshooting. Free parts provided within the warranty period.
·Customization: Design, samples, and packaging tailored to client specifications.
·Warranty: Standard 2-year warranty, extendable up to 5 years.
·Turnkey Commercial EV Charging: Comprehensive solutions designed to enhance businesses with easy-to-use EV chargers. Compatible with Open Charge Point Protocol (OCPP), offering user-friendly management and data access.
·Custom Branding Options: Personalized branding and design features to enhance brand visibility at charging points.
·Advanced Safety Features: Overvoltage and overload protection, intuitive interface, and seamless energy management system integration for optimized power use and operational reliability.
·Easy Installation and Maintenance: Designed for straightforward setup and minimal upkeep, with ongoing maintenance services to ensure optimal operation.
Q: What benefits do businesses gain by installing a commercial EV charging station?
A: Installing a commercial EV charging station can help attract new customers and increase revenue through hourly or daily charging plans. Additionally, many local authorities offer tax incentives to offset installation costs, which can include discounts on electricity rates or reimbursement of installation fees.
Q: What’s the main difference between DC and AC EV charging?
A: The key difference is in charging speed. DC chargers can charge a battery up to 80% in about 30 minutes, while AC chargers generally take much longer. DC charging is faster but tends to be more expensive, making it ideal for high-speed, high-demand scenarios. AC charging is more economical and better suited for slower, routine charging.
Q: Are commercial EV chargers compatible with all types of connectors?
A: Yes, Anari’s commercial EV chargers support international standards, including CCS 1 for North America, CHAdeMO for Japan, and CCS 2 for Europe. This compatibility ensures broad usability across different regions and vehicle types.
Q: How do Anari charging stations perform in various weather conditions?
A: Our charging stations are optimized for all weather conditions, with built-in temperature control and circuit protection to ensure reliable performance. These features protect the station’s internal components from voltage spikes or extreme temperatures, enhancing both durability and safety.
Q: What is the power output range for commercial EV chargers, and why is this important?
A: The power output for Anari fast charging station ranges from 180 kW to 360 kW. Higher power output means faster charging, making these chargers ideal for high-demand areas like shopping centers, airports, and workplaces where customers may need to recharge quickly.
Shenzhen Anari Energy Co., Ltd.
Driven by innovation and excellence.
Mission Statement:
Anari is committed to delivering top-quality EV charging products and services that promote sustainable growth and ensure customer satisfaction.
Introduction:
Shenzhen Anari Energy Co., Ltd. (Anari), a subsidiary of Boyang Group, has operated independently since 2021 and is recognized as a leading AC EV charging company and DC EV charging company. Anari specializes in the R&D, production, and sales of EV chargers and provides comprehensive solutions as a prominent EV charging solutions company. Headquartered in Shenzhen, Anari has also expanded internationally with branches in Xi'an, Turkey, and the UK, catering to a global clientele of over 100 customers across 22 countries. Known for its fast, efficient, and user-friendly charging solutions, Anari meets the diverse requirements of commercial and residential EV charging stations around the world.
DC Wallbox 30kW / 40kW: Compact, powerful wall-mounted chargers suitable for home and business installations.
DC Fast Charging Station: High-capacity charging for quick, efficient energy delivery, ideal for high-demand locations.
AC Wallbox 7.4kW / 11kW / 22kW: Versatile wall-mounted EV charging stations for home and business, featuring the pulsar plus model for advanced, user-friendly operation.
Range includes both AC and DC EV chargers for varying charging needs, including high-efficiency car chargers and flexible charging station options.
