7-22kW Type 2 Floor-mounted Public Charging Stations For 99% Electric Vehicles

7kW, 11kW, 22kW
IP55 (Enclosure IP66) IK10
OCPP1.6J

Product Features

Solar Compatible

All day charging with PV surplus power and off-peak electricity
Long Lasting

Up to 10000 times charging, Suitable for commercial&household use
Compatible

Compatible with 99% of electric vehicles on the market
Easy to Install

Hassle-free experience with easy installation

Product Description

The 7-22kW Type 2 Floor-mounted Public Charging Station is suitable for both commercial and household product among Anari Energy’s AC charging station, available in three models of 7/11/22kW. It can provide charging services for 99% of electric vehicles on the market. Its most prominent feature is that it can utilize surplus PV power and off-peak electricity for charging throughout the day, making it suitable for charging station operators or installers in regions with significant electricity price fluctuations.

Specifications

Power Specification	Model Number	A07W1SC	A11W1SC	A22W1SC
	AC Power Input Rating	230VAC	380VAC	380VAC
	Rated Frequency	50/60Hz
	Input Current	32A	16A	32A
	Output Power	7.4kW	11kW	22kW
	Connector Type	Type 2 Cable/5m or Type 2 Socket (Lockable)
User Interface Control	Charging Control	Plug and Charge, RFID Card or APP
	LCD Display	4.3” LCD Non-touch Screen
	Connectivity	Wifi + Ethernet, 4G (Optional), Solar Compatiable(Optional)
	OCPP Protocol	OCPP1.6, Including Smart Charging
Environmental	Storage Temperature	-40 to 65℃ Ambient
	Operating Temperature	-30 to 50℃ Ambient
	Operating Humidity	Up to 95% Non-condensing
	Cooling Method	Natural Cooling
Protection	IP/IK Code	IP55 (Enclosure IP66) IK10
	RCD	AC 30mA + DC 6mA
	Electrical Protection	Over Load Protection, Over Current Protection, Residual Current Protection, Short Circuit Protection, Ground Protection, Surge Protection, Over/Under Voltage Protection, Over/Under Frequency Protection, Over/Under Temperature Protection, O-PEN Protection(optional for UK)

Application Scenarios

FAQ

Product Introduction

Designed for both commercial and residential applications, the Anari Energy 7–22kW Type 2 Public Charging Station offers a versatile AC charging solution. The unit supports three power output levels – 7kW, 11kW, and 22kW – to accommodate different usage scenarios and vehicle requirements.

Key features include plug-and-play charging, flexible payment options (RFID card or OCPP), and multiple network connectivity choices (Wi-Fi, Ethernet, and 4G). The station is equipped with a 4.3-inch non-touch LCD screen and boasts an IP55 protection rating, ensuring reliable operation in outdoor environments. Installation is adaptable to both column-mounted and wall-mounted configurations.

The most notable advantage of this charging station is its seamless integration into a "photovoltaic + energy storage" ecosystem – a highly beneficial feature for operators who have already deployed PV and energy storage systems.
